Optimised safety and comfort
ConceptSystem 77 doors are a robust and versatile solution, offering exceptional performance and a modern aesthetic for residential and commercial projects. With advanced thermal insulation, enhanced security features, and compatibility with triple glazing, these doors deliver efficiency without compromising style. Their durable aluminum construction ensures longevity, while a wide range of customization options allows for seamless integration into any architectural design. Ideal for meeting high standards in energy efficiency and safety, ConceptSystem 77 doors provide an excellent balance of functionality and elegance.
  • Safe and versatile door solution to match any project needs
  • Well-balanced price-performance-features mix
  • Reliable doors that last a lifetime
Request More Information
Product options

ConceptSystem 77 is a versatile and reliable door system with a strong legacy. It offers a complete range of design options and safety features, including fireproof and bulletproof variants. Incorporate a trusted aluminum solution that meets standard performance levels. Personalize ConceptSystem 77 with the following options:

The available options depend on size, profile combinations, hardware, and infill choices.

Low Threshold

Easy access, cleaner look

Zero Threshold

Entrance without boundaries, even with continuous flooring

Concealed Hinges

The details are the design, concealed hinges are the finishing touch

Concealed Drainage

No more plastic cover caps, enjoy those clean lines

Access Control

Making your home smart and connected

Panic

Tried and tested, for peace of mind

Technical details

THERMAL INSULATION
High
Uf = 1.8 W/m²K
Ud = 1.4 W/m²K

AIR-WATER-WIND
High
4/7A/C2

ACOUSTICS
High
Rw(C;Ctr) = 42(-1;-4) dB

HEIGHT VENT
Max 3000 mm

BURGLAR RESISTANCE
RC2 – RC3 – PAS 24

SYSTEM DIMENTIONS
Min. Frame-Vent Width
150 mm
Depth Frame 68 mm
